CPK High Precision Automatic SMD Led Chip Smd Mounting Machine CHM-750
CHM-750 Pick and Place Machine is characterized by 50 feeder stacks, 6 heads capable of 360-degree rotation,support for Yamaha pneumatic feeders ,stick feeders with tubular components, automatic correction to pick components, suction nozzles can be changed automatically,integrated operation with built-in industrial computer.
Types of SMT Pick and Place Machine
Pick and place machines for fine pitch (0.5mm) and ultra fine pitch (0.4mm – 0.3mm) placement machines require greater dexterity and precision placement capability. Some of these machines cut and form the leads of the IC package at the time of placement in order to avoid component lead damage due to mishandling. This feature increases process accuracy and precision capabilities.
The number of machines required to adequately assemble all surface mount components varies depending on the type of components being assembled, Type of PCB and the through-put desired by the manufacturer.
| CHM-750 Specifications |
| Dimensions | 1280mm(L)×1190mm(W)×1470mm(H) |
| Weight | 520kg |
| Power Supply | AC220V (50Hz, single phase), 2.8kW |
| Air Supply | 0.5MPa ~0.7MPa |
| Vacuum Generation | Vacuum generator |
| Mounting Head Quantity | 6 |
| Mounting Speed | 17000cph (optimal) IPC9850 : 12000CPH |
| Mounting Accuracy | ±50μm CPK≥1.0(XY) |
| Component Height | 12mm |
| Component Type | 0201/0402/0603～5050/SOT/SOP/QFP/QFN/BGA, etc. (resistor/capacitor/diode/triode/LED/IC, etc.) |
| PCB Thickness | 0.6mm~3.5mm |
| PCB Size | 400mm(L)×350mm(W) |
| PCB Conveying | 3-section-rail automatic conveying |
| Nozzle Change | Automatic nozzle change (19-hole nozzle library) |
| Control System | Built-in industrial computer (Windows 7) equipped with monitor, keyboard, and mouse |
| Drive System | X&Y axis driven by servo motors (Y axis by double motors); adopting flexible S-curve acceleration and deceleration |
| Transmission System | Ball screw + linear guide (Y axis with double screws) |
| Feeding System | 50 Yamaha 8mm standard pneumatic/electric feeder stacks (also suitable for IC tray and stick feeder) |
| Vision System | Snapshot camera×6 (component size applicable: 16mm×16mm); IC camera×1 (component size applicable: 36mm×36mm); Mark camera×2 |
